MOBE-500
Product Description
- Standard Specification
- Optional Specification
- Related Product
- Download
|
Items |
Specification |
MOBE-501 |
MOBE-502 |
|
Viewing Head |
Sliding Binocular Head |
● |
● |
|
Sliding Trinocular Head |
○ |
○ |
|
|
Seidentopf Binocular Head |
○ |
○ |
|
|
Anti-mould |
○ |
● |
|
|
Eyepiece |
WF10X |
● |
● |
|
P16X |
○ |
○ |
|
|
Nosepiece |
Quadruple Nosepiece |
● |
● |
|
Quintuple Nosepiece |
○ |
○ |
|
|
Objective |
Achromatic Objective 4X,10X,40X,100X |
● |
● |
|
Stage |
Double Layers Mechanical Stage 140X140mm/ 75X50mm |
● |
● |
|
Condenser |
Abbe NA1.20 with Iris Diaphragm & Filter |
● |
● |
|
Focusing System |
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm |
● |
● |
|
Armrest |
Black Armrest |
○ |
● |
|
Rubber Cover |
Rubber Cover for Focus Adjustment Knob |
○ |
● |
|
Illumination |
S-LED Illumination, Brightness Adjustable |
● |
● |
|
Halogen Lamp 100V-240V/ 6V20W |
○ |
○ |
|
|
Plan-concave Mirror |
● |
● |
|
|
Package |
Styrofoam |
● |
● |
|
Carton |
● |
● |
|
|
Wooden Case |
