MOBE-600
Product Description
- Standard Specification
- Optional Specification
- Related Product
- Download
|
Items |
Specification |
MOBE-600 |
|
Viewing head |
Seidentopf Binocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm |
● |
|
Eyepiece |
WF10×/18 |
● |
|
WF16×/12 |
||
|
Objective |
Achromatic Objective 4×, 10×, 40×, 100× |
● |
|
Plan Achromatic Objective 4×, 10×, 40×, 100× |
||
|
Infinite Plan Achromatic Objective 4×, 10×, 40×, 100× |
||
|
Focusing System |
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 20mm |
● |
|
Nosepiece |
Quadruple Nosepiece |
● |
|
Stage |
Double Layers Mechanical Stage132×142mm/75×40mm |
● |
|
Condenser |
Abbe Condenser NA1.25 with Aperture Diaphragm |
● |
|
Dark Field Condenser |
||
|
Illumination |
LED |
● |
|
12V/20W Halogen Lamp, Brightness Adjustable |
||
|
Kohler Illumination |
|
Viewing head |
Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm |
