- After years of research and development in optical technology field, F-500 biological microscope is designed to present a safe, comfortable and efficiency observation experience for users. With perfectly performed structure, high-definition optical image and simple operating system,F-500 realizes professional analysis, and meets all the needs of research in scientific, medical and other fields.
- Large stage with adjustment in either hand In order to correct the shortcoming of horizon guide rail, new stage is designed with double-way linear driving mechanism. This change protects the stage from overload at the end of both rails, improves the rigidity and performance of the stage.
- The handle of the stage can be set at each side based on users’ preference. The X, Y biaxial adjustment is designed with low position for comfortable operation.
- Two slices can be held on the stage by using damping-type double clips, easy for comparative study. Moving range: 80mm X55mm; precision: 0.1mm Processed with special craft, the surface of the stage is anti-corrosive and anti-friction. The platform with an arc transition design reduces the stress concentration and damage from impact.
- Light barrier, which can effectively reduce the stray light, improves the image contrast in fluorescence observation.
- Modular frame, improve the system compatibility F-500 with modularization design, separated cross arm and main body, improves the system compatibility of biological and fluorescence frame.
- Highly sensitive coaxial coarse and fine adjustment, coaxial adjustment adopts double-stage driving, with adjustable tension tightness and upper limit stop, coarse range is 25mm and fine precision is 1μm. Not only accurately focus but also precision measurement is available.
- Viewing head with multi-splitting ratio F-500 viewing head is designed of multiple options for splitting ratio. With wide beam imaging system, 26.5mm super wide field of view is available.
- Trinocular head with inverted image, splitting ratio Binocular: Trinocular=100:0 or 20:80 or 0:100. Except for concentrating 100% light to eyepiece tube or camera tube, there is another option with 20% light to eyepiece tube and 80% to camera tube, so that eyepiece observation and image output can be available at the same time.
- Trinocular head with erect image, splitting ratio Binocular:Trinocular= 100:0 or 0:100. The moving direction of samples is as the same as observed.
F-500
Product Description
- Standard Specification
- Optional Specification
- Related Product
- Download
|
Items |
SPECIFICATION |
F-501 |
F-502 |
F-503 |
F-504 |
|
Eyepiece |
High-eye point Plan eye piece PL10X/25mm，diopter adjustable |
●● |
●● |
●● |
●● |
|
High-eye point Plan eye piece PL10X/25mm, diopter adjustable, with micrometer |
|
|
|
||
|
High-eye point Plan eye piece PL10X/26.5mm, diopter adjustable |
|
|
|
||
|
Viewing Head |
30°inclined, inverted image，infinity l trinocular head with interpupillary distance 50~76mm，three split ratio 0：100；20：80；100：0 |
● |
● |
|
|
|
30°inclined, erect image，infinity trinocular head with interpupillary distance 50-76mm，split ratio 100：0 or 0：100 |
|
● |
● |
||
|
Objectives |
Plan semi-apo chromatic fluorescent objective 4X/0.13(infinity），WD=18.5mm |
● |
● |
● |
● |
|
Plan semi-apo chromatic fluorescent objective 10X/0.30(infinity），WD=10.6mm |
● |
● |
● |
● |
|
|
Plan semi-apo chromatic fluorescent objective 20X/0.50(infinity），WD=2.33mm |
● |
● |
● |
● |
|
|
Plan semi-apo chromatic fluorescent objective 40X/0.75(infinity），WD=0.6mm |
● |
● |
● |
● |
|
|
Plan semi-apo chromatic fluorescent objective 100X/1.30(infinity），WD=0.21mm |
● |
● |
● |
● |
|
|
nosepiece |
BF quintuple nosepiece(with socket for DIC) |
|
|
|
|
|
BF sextuple nosepiece(with socket for DIC) |
● |
● |
● |
● |
|
|
BF septuple nosepiece(with socket for DIC) |
|
|
|
||
|
Stand |
(For transmission biological microscope) Coaxial focus system with upper limited and tension adjustment, coarse adjustment range: 25mm, fine adjustment precision: 0.001mm. 100-240V built-in wideband voltage transformer, adopt digital dimming, with the function of light set and reset, built-in filter(LBD,ND6,ND25) |
|
|
|
|
|
|
(For transmission fluorescent microscope) Coaxial focus system with upper limited and tension adjustment, coarse adjustment range: 25mm, fine adjustment precision: 0.001mm. 100-240V built-in wideband voltage transformer, adopt digital dimming, with the function of light set and reset, built-in filter(LBD,ND6,ND25) |
● |
● |
● |
● |
|
Six position disc reflection fluorescent Koehler illumination with IRIS diaphragm and aperture diaphragm(all center adjustable). Socket for filter inserter and polarizer device, with the fluorescent light shield in the front. |
● |
● |
● |
● |
|
|
Fluorescence Attachment |
100W mercury lamp house |
● |
● |
● |
● |
|
Digital power control box of mercury lamp, voltage 90-240V |
● |
● |
● |
● |
|
|
Imported 100W DC mercury bulb(OSRAM) |
● |
● |
● |
● |
|
|
Fluorescence filter（UV）(CHROMA) |
● |
|
● |
||
|
Fluorescence filter（V）(CHROMA) |
● |
|
● |
||
|
Fluorescence filter（B）(CHROMA) |
● |
● |
● |
● |
|
|
Fluorescence filter（G）(CHROMA) |
● |
● |
● |
● |
|
|
Attenuation plate（transmittance 25%） |
|
|
|
||
|
Attenuation plate（transmittance 50%） |
● |
● |
● |
● |
|
|
illumination |
12V100W halogen lamp house (centered) |
● |
● |
● |
● |
|
12V/100W halogen bulb（Philips 7724) |
●● |
●● |
●● |
●● |
|
|
75W Xenon lamp house,(for reflection), the center of filament can be adjusted. |
|
|
|
||
|
75W Xenon lamp（OSRAM） |
|
|
|
||
|
Power control box of Xenon lamp. |
|
|
|
||
|
Stage |
187x166mm double layer mechanical stage, moving range 80x55mm，Precision 0.1mm，bidirectional transmission, left and right position handle for option. Tension of the torque is adjustable. |
● |
● |
● |
● |
|
condenser |
Swing-out achromatic condenser (NA 0.9） |
● |
● |
● |
● |
|
Universal condenser |
|
|
|
||
|
|
Mercury bulb centered objective |
● |
● |
● |
● |
|
|
Allen key（For M4） |
● |
● |
● |
● |
|
|
Allen key（For M5） |
● |
● |
● |
● |
|
Optional Accessories |
0.5X CTV,C-mount, focusable |
|
|
|
|
|
0.65X CTV，0.65X CTV， |
|
|
|
||
|
Center eyepiece（ø30） |
|
|
|
||
|
High precision micrometer, 0.01mm |
|
|
|
||
|
Professional software for fluorescence observation |
|
|
|
