Items

Specification

F-201

F-202

F-203

F-204

Eyepiece

Plan eyepiece PL10X/20mm，adjustable diopter

●●

●●

●●

●●

Plan eyepiece PL10X/22mm，adjustable diopter

Infinity plan achromatic objective

Infinity plan achromatic objective 2X/0.06,WD=5.03mm

Infinity plan achromatic objective 4X/0.10,WD=7.18mm

Infinity plan achromatic objective 10X/0.25,WD=4.70mm

●

●

●

●

Infinity plan achromatic objective 20X/0.50,WD=1.75mm

●

●

●

●

Infinity plan achromatic objective 40X/0.65,WD=0.72mm

●

●

●

●

Infinity plan achromatic objective 100X/1.25,WD=0.15mm

●

●

●

●

Infinity phase contrast objective

Infinity phase contrast objective 10X/0.25 WD=4.70mm

Infinity phase contrast objective 20X/0.50 WD=1.75mm

Infinity phase contrast objective 40X/0.65 WD=0.72mm

Infinity phase contrast objective 100X/1.25 WD=0.15mm

Viewing head

30°gemel binocular, eyepiece tube can rotate 360°，interpupillary distance range 50-75mm

30°gemel trinocular, eyepiece tube can rotate 360°，interpupillary distance range 50-75mm, fixed spectroscopical ratio R：T=8：2

●

●

●

●

Body

Coaxial coarse and fine focusing system, with upper limit and tightness adjustment. 100V-240V fluctuate of voltage, single 3W LED (predetermine filament center), adjustment of brightness.

●

●

●

●

Coaxial coarse and fine focusing system, with upper limit and tightness adjustment. 100V-240V fluctuate of voltage, Philips 6V30W halogen lamp (predetermine filament center), adjustment of brightness.

LED fluorescent reflected illumination

UV2 ultraviolet long-pass type LED module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength: 365mm

●

B4 LED fluorescence module dedicated for TB, with with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength: 455mm

●

B1 band-pass type fluorescence module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength:470mm

●

G1 band-pass type LED fluorescence module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength: 560mm

●

Other various LED module for option, which can be custom-tailor according to the needs of clinical diagnosis.

Nosepiece

Reversed quadruple nosepiece

●

●

●

●

Reversed quintuple nosepiece

Stage

150mmX140mm mechanical stage with underhand, 76X50mm moving range, precision 0.1mm, damping clips

●

●

●

●

condenser group

N.A.1.25 Koehler illuminator condenser group(with socket for phase contrast device and dark-field device)

●

●

●

●

Filter

blue filter（ø45）

yellow filter（ø45）

green filter（ø45）

neutral filter（ø45）

Other optional accessory

eyepiece reticule，precision：0.1mm

grid（for eyepiece）

High precision reticule, 0.01mm

Ordinary precision reticule，0.01mm

1XCTV C-mount，adjustable

1/2（0.5X） C-mount，adjustable

1/3（0.35） C-mount，adjustable

Dark-field accessories, for 4X-40X objective (as light guade for LED fluorescence microscope)

Centering eyepiece（ø30）

Phase contrast accessories, for 10X and 40X objective

Phase contrast accessories, for 20X and 100X objective

N.A.1.25 Koehler illuminator disc phase contrast condenser, for 10X,20X,40X,100X phase contrast observation

N.A.1.25 Koehler illuminator disc phase contrast and dark field condenser group, for 10X,40X,100X phase contrast observation and 4X-40X dark field observation

Polarizer set

Analyzer set

Allen key

Allen key M3

●

●

●

●

Allen key M1.6

●

●

●

●
