Items
|
Specification
|
F-301
|
F-302
|
|
eyepiece
|
High eye point plan eyepiece PL10X/22mm
|
●
|
●
|
|
High eye point plan eyepiece PL10X/22mm w/reticule
|
|
|
|
High eye point plan eyepiece PL15X/16mm
|
|
|
|
Plan semi-apo
Chromatic
Fluorescence
objectives
|
Plan semi-apo chromatic fluorescence objective 4X/0.13（infinity）,WD=15.3mm
|
●
|
●
|
|
Plan semi-apo chromatic fluorescence objective 10X/0.30（infinity）,WD=8.7mm
|
●
|
●
|
|
Plan semi-apo chromatic fluorescence objective 20X/0.50（infinity）,WD=2.5mm
|
●
|
●
|
|
Plan semi-apo chromatic fluorescence objective 40X/0.75（infinity）,WD=0.72mm
|
●
|
●
|
|
Plan semi-apo chromatic fluorescence objective 100X/1.30（infinity）,WD=0.21mm
|
●
|
●
|
|
Telescope
|
Telescope of fluorescence
|
●
|
●
|
|
Viewing head
|
30°inclined gemel binocular head 360°rotating（infinity）,inter-pupillary range:54~75mm; Diopter adjustment±5
|
|
|
|
30°inclined gemel trinocular head 360°rotating（infinity）,inter-pupillary range:54~75mm; Diopter adjustment±5.B:T=0:100 or 50:50
|
|
|
|
30°inclined gemel trinocular head 360°rotating（infinity）,inter-pupillary range:54~75mm; Diopter adjustment±5.B:T=0:100 or 100:0
|
●
|
●
|
|
Efficient infinity gemel binocular head,30º-60ºadjustable elevation,360°rotating,inter-pupillary range:54~75mm; Diopter adjustment±5 either side.
|
|
|
|
nosepiece
|
quintuple nosepiece
|
●
|
●
|
|
quadruple nosepiece
|
|
|
|
adjusting system
|
Coaxial coarse and fine adjusting system, with tightness adjustment and upper limited, coarse adjustment range 25mm,fine adjustment precision:0.002mm,
|
●
|
●
|
|
Stage
|
175×145mm double layer mechanical stage, with X,Y moving hand wheel in right hand, moving range 76X50mm,precision:0.1mm
|
●
|
●
|
|
condenser
|
NA1.2/0.22 swing out achromatic condenser with marked iris diaphragm
|
●
|
●
|
|
NA1.25 quintuple disc phase contrast condenser (infinity)
|
|
|
|
illumination
|
6V30W halogen bulb house, presetting the center of filament
|
●
|
●
|
|
Imported long life 6V/30W halogen bulb
|
●●
|
●●
|
|
filter
|
Yellow filter（ø45）
|
|
|
|
Green filter（ø45）
|
|
|
|
Blue filter（ø45）
|
●
|
●
|
|
Neutral filter（ø45）
|
|
|
|
attenuation plate
|
30ND25 attenuation plate (For disc filter blocks switching mechanism)
|
●
|
●
|
|
30ND50 attenuation plate (For disc filter blocks switching mechanism)
|
|
|
|
Adapter
|
3.2X photo ocular,photo tube (with PK or MD adapter)
|
|
|
|
1XCTV
|
|
|
|
2/3CTV
|
●
|
●
|
|
1/2CTV
|
|
|
|
C adapter of Digital camera
|
|
|
|
|
Special micrometer,precesion:0.01mm
|
|
|
|
Micrometer,precesion:0.01mm
|
|
|
|
Dark field condenser
|
NA0.9 dry dark field condenser
|
|
|
|
NA1.25 oil dark field condenser
|
|
|
|
Polarization
attachment
|
Polarizer（ø45）
|
|
|
|
Analyzer inserter
|
|
|
|
Incident wave inserter（λ inserter)
|
|
|
|
Rotating stage
|
|
|
|
Fluorescence
attachment
|
Reflection fluorescence illuminator for disc filter blocks switching mechanism
|
●
|
●
|
|
100W Mercury lamp house
|
●
|
●
|
|
Mercury lamp power control system
|
●
|
●
|
|
Eye guard
|
●
|
●
|
|
100W Mercury lamp（OSRAM）
|
●
|
●
|
|
100W Mercury lamp （Made in China）
|
|
|
|
fluorescence filter
|
fluorescence filter（UV）（CHROMA）(For disc filter blocks switching mechanism)
|
|
●
|
|
fluorescence filter（V）（CHROMA）(For disc filter blocks switching mechanism)
|
|
●
|
|
fluorescence filter（B）（CHROMA）(For disc filter blocks switching mechanism)
|
●
|
●
|
|
fluorescence filter（G）（CHROMA）(For disc filter blocks switching mechanism)
|
●
|
●
|
|
|
Non fluorescence oil(30ml)
|
●
|
●
|
|
|
Spanner M5
|
●
|
●
|
